The user-friendly design of the printer facilitates a ribbon length of up to 360 metres and a roller core diameter of up to 203 mm (8 inches), meaning fewer user interventions are necessary.



In addition to the Ethernet interface, the DL-820 can also be configured with a large number of optional accessories. These make it ideal for use in many sectors, such as logistics and production or healthcare.

Highlights at a glance
  • High Speed Printing
  • Easy Paper Loading
  • USB and Ethernet Interfaces as standard
  • Supports ZPL and EPL emulation
  • 360 m ribbon roll
  • Support of 8 inch media roll
  • LCD display for easy administration


Models

  • DL-820 standard model
  • DL-820 model with cutter
  • DL-820 model with peeler
Thermal Printer DL-820

Thermal Printer DL-820

Print head Direct-thermal or thermal-transfer
Print speed up to 203 mm/sec.
Print volume up to 500 m/month
Resolution 203 dpi
Interfaces 1x USB, 1x Ethernet
Emulations ZPL, EPL, TSPL
Print width 108 mm
Models, options and consumables
Model overview
  • Tally Dascom DL-820 USB/Ethernet (Part-No. 28.920.0132)
  • Tally Dascom DL-820 USB/Ethernet/parallel (Part-No. 28.920.0143)
  • Tally Dascom DL-820 USB/Ethernet/serial (Part-No. 28.920.0147)
  • Tally Dascom DL-820 with cutter USB/Ethernet (Part-No. 28.920.0644)
  • Tally Dascom DL-820 with cutter USB/Ethernet/parallel (Part-No. 28.920.0655)
  • Tally Dascom DL-820 with cutter USB/Ethernet/serial (Part-No. 28.920.0659)
  • Tally Dascom DL-820 with peeler USB/Ethernet (Ar.,-Nr. 28.920.0388)
  • Tally Dascom DL-820 with peeler USB/Ethernet/Par. (Part-No. 28.920.0399)
  • Tally Dascom DL-820 with peeler USB/Ethernet/Ser. (Part-No. 28.920.0403)

interfaces

  • W-LAN interface (Part-No. 390 310 21)

Consumables

  • Ribbon wax (4 inch) (Part-No. 043 970)
  • Ribbon wax (2 inch) (Part-No. 043 971)
  • Ribbon wax/resin (4 inch) (Part-No. 043 972)
  • Ribbon wax/resin (2 inch) (Part-No. 043 973)
  • Ribbon resin (4 inch) (Part-No. 043 974)
  • Ribbon resin (2 inch) (Part-No. 043 975)
Marketing information
Brochure thermal printer
Data sheet
Alternative products
Thermal Printer 7010/7010R
Tally Dascom 7010/7010R
